Product Description:
The Optical Power Meter is an essential tool designed for professionals working in the field of fiber optic communications and network maintenance. This device provides accurate and reliable measurements of optical power levels, ensuring optimal performance and troubleshooting of fiber optic systems. With a robust design and user-friendly interface, the Optical Power Meter is suitable for a wide range of applications, from installation and maintenance to research and development.
One of the key features of this Optical Power Meter is its broad wavelength range compatibility. It supports a wide spectrum, allowing users to measure power accurately across different wavelengths commonly used in fiber optic networks. This capability ensures that the device can be employed in various setups without the need for multiple meters, thus enhancing efficiency and reducing costs. The precise wavelength range coverage makes it ideal for testing single-mode and multi-mode fibers, providing versatile functionality for diverse optical systems.
The measurement range of this Optical Power Meter spans from +5 to -70 dBm, delivering high sensitivity and precision in detecting optical power levels. Whether you need to measure very low power signals or strong optical outputs, this meter can handle it with ease. This wide measurement range is particularly beneficial for evaluating the performance of optical transmitters and receivers, verifying signal strength, and ensuring that optical links meet the required standards.
| Model # |
U8204 |
| Number of Channels |
4 |
| Power Range |
+5 ~ -70dBm |
| Wavelength Range |
850 ~ 1700 nm |
| Calibration Wavelength |
850/908/1270/1290/1310/1330/1510/1530/1550/1570 nm |
| Sampling period |
100 us (10KHz) |
| Application Fiber Type |
Standard SM and MM up to 62.5 um core size |
| AbsoluteUncertainty (accuracy) at reference condition |
± 4% (1200 nm ~ 1610 nm) |
| Relative Uncertainty (accuracy) at reference condition |
＜ 0.02 dB Typical |
| Linearity (power) |
≤ ± 0.06 dB (1200 nm ~ 1610 nm, 0~ -50dBm) |
| Return Loss |
＞ 40 dB |
| Operation Temperature |
0 ～ +40℃ |
| Storage Temperature |
-30 ～ +80℃ |
| Recalibration Period |
2 years |
| Dimensions |
245 mm W, 105 mm H, 320 mm D |
| Weight |
2.0 kg |
Applications:
The YOUCii U8204 Optical Power Meter is a versatile and reliable tool designed for a wide range of applications in the fiber optic communication industry. Its double channel design allows simultaneous measurement of two optical signals, making it ideal for complex network setups and ensuring efficient workflow. This product is prominently used in telecommunications, data centers, and network maintenance where precise optical power measurements are critical.
Thanks to its broad measurement range from +5 to -70 dBm, the U8204 Optical Power Meter can accurately measure both very low and very high power levels, catering to various fiber optic systems. The device supports a wide wavelength range, allowing technicians to test signals across different wavelengths used in modern fiber optic networks. This capability is essential for comprehensive network analysis and troubleshooting, including assessing return loss, which is a key parameter in evaluating the quality of fiber optic links and connectors.
